ASLF 'Anti-Strap-Loss-Function' Constant strap control
Automatic Strap feed
Operation Terminal with Soft-Button
DAT 'Direct-Access-Technology'
Torque controlled strap tension, adjustable
Tension adjustable with 10 steps
Wear-free, energy saving direct-drive-motors
Low maintenance and low wear strap arch
Many specific options available, easily configurable
Integrated compact reservoir
TECHNICAL SPECIFICATION
CAPACITY
Single strap, bundles/minute up to
50
Based on bundle size l x w in mm
500x550
Depending on arch size and tension force
BUNDLES
Width in mm
min. 55
Max. bundle width depending on arch size
Height in mm
min. 80
Max. bundle height depending on arch size
(see drawing)
Weight in kg
max.
STRAP TENSION
Adjustable with 10 steps
Tension at bundle in N
max. 600
STRAPPING MATERIAL
PP and PET Strap DIN EN 13 394
Width in mm
12 - 15
Thickness in mm
0.4 - 0.9
SEALING METHOD
Heat seal. Tensile strength of welded joint is approx. 60 - 80 % of the breaking strength of the strap
POWER SUPPLY
Wide Range Input 100-240V, 1AC; 47-63 Hz
optional
Wide Range Input 380-520V, 3AC; 47 63 Hz
Maximum fusing 16A (B-character)
Protection Type
IP 22
POWER CONSUMPTION
Power consumption in kW approx.
0,5
WEIGHT
Total weight approx. in kg
90
OPERATING CONDITIONS
Temperature range in °C [°F]
max. 50
Technologies
The Direct-Access-Technology allows direct access to the strap in the strap drive. The strap drive can be opened very quickly without tools by pressing an ergonomic control lever. The defective strap or a resulting disturbance can be easily dealt with in seconds. After closing the strap drive work can continue immediately.
Beschreibungsbox XS
The Anti-Strap-Loss-Function ensures that the strap no longer gets lost in the machine and is permanently available for the function modules. The machine is thus resilient to malfunction in the production process, which in turn increases the machine availability.
Beschreibungsbox XS
Beschreibungsbox SM
The new strapping machines by SMB need up to 50% less energy than conventional machines.
Energy recovery, highly efficient drives, standard on-board voltage and also low-friction mechanical components are attributes of the new SMB technology.
Beschreibungsbox XS
Beschreibungsbox MD
The most important thing for you as the operator is when your packaging machine runs as long as possible with high availability as at the beginning of the product life. This characteristic is achieved by simple and robust design, targeted selection of suitable materials and as few actuators as possible.
This enables us to clearly distinguish ourselves from the usual machines of our competitors. For you this means a noticeably higher Overall Equipment Effectiveness (OEE).
